A versatile tread with a stepped lug design for added protection from stone trapping. Allows flexibility in applications from smooth haul roads to rough and rocky terrain while providing maximum productivity.
MS440 PRO
Off-The-Road-Tires
Discover our range of performance off-the-road solutions that maximize productivity with lower cost-per-hour, performance and value for the toughest OTR applications.
MS440 PRO
E4
Description
Features
- Excellent traction in all haul road conditions
- Deep tread grooves provide cooler running tread for high site TKPH
- Optimized lower sidewall profile to prevent separations in that area
- Wide, square footprint distributes load for minimal haul road disturbance
- Reinforced bead, shoulder and sidewall for increased cut resistance
- Heat resistant undertread reduces tire temperature
- Multiple tread compound options target specific site requirements
Downloads
Applications
| Size | Rating | Type | Rim | O.D. | S.W. | T.D. | Tread Compound | TMPH/TKPH | Infl. | L.C.C. | L.I. |
|---|---|---|---|---|---|---|---|---|---|---|---|
| in mm |
in mm |
32nds mm |
psi kPa |
30 mph 50 kph |
|||||||
| 46/90R57 | ** | TL | 32.00/6.0 | 140.6 3571 |
45.2 1148 |
121 96 |
Cut Resistant (S2) | 514/750 | 102 700 |
139000 63000 |
252B |
| 46/90R57 | ** | TL | 32.00/6.0 | 140.6 3571 |
45.2 1148 |
121 96 |
Standard (S1) | 617/900 | 102 700 |
139000 63000 |
252B |
| 46/90R57 | ** | TL | 32.00/6.0 | 140.6 3571 |
45.2 1148 |
121 96 |
Heat Resistant (S3) | 737/1075 | 102 700 |
139000 63000 |
252B |
* Applications with load requirements exceeding the published values must be reviewed and approved by Maxam Tire. Please contact your Maxam Tire representative for more details.
